EPS12V ATX12V项目内容
|
Introduction
| Complies With The Latest Intel | EPS12V / ATX12V | ||||
| Model | CSH (G) Series | ||||
| Dimension | V:150*160*86mm (14cm Fan) | ||||
| Protection | OCP/OVP/UVP/OPP/SCP/OTP | ||||
| Meet Eup Requirements | 2013 | ||||
| Efficiency | 1000W 80 Plus (Gold) | ||||
| AC INPUT | 100V~240V | ||||
| Input Frequency | 47Hz~ 63 Hz | ||||
| Active PFC | Power Factor : >0.9 | ||||
| Output Power | 1000W | ||||
| Voltage | +12V | +3.3V | +5V | +5VSB | -12V |
| Max Load | 83.3A | 25A | 25A | 3A | 0.8A |
| Combined Power | 999.6W | 130W | 15W | 9.6W | |
